LED film series adopts modular design, with transparent display, ultra-thin flexible display, ultra-transparent, fast installation, energy saving and environmental protection. Can be directly attached to the glass curtain wall and window. Widely used in glass window, large shopping malls, French window, high-end exhibition hall, auto glass, landmarks such as the scene.
Unobstructed Light Transmission | >85% Transparency
Ultra-thin, fully transparent panels with >85% light transmission — lightweight yet durable1
Smart Control | App + Wireless Sync
Multi-device wireless display synchronization via smartphone
Carbon Fiber Ice Screen™
Seamless wireless content sharing (videos/images) with instant social media integration
Fully Transparent Panels | Ultra-Lightweight
Crystal Film Screen: weighs only 3kg/m² — the lightest in its class
Modular Design | Easy Assembly
Customizable to any size without steel frameworks — tool-free, rapid installation
Low-Brightness High-Gamut | 200-5000cd/m²
Exceptional color accuracy (high grayscale/saturation) even at low brightness
| Model | CF3.9X7.8 | CF7.8 | CF10.4 |
Pixel pitch | 3.9/7.8mm | 7.8125mm | 10.416mm |
Weight | 0.8kg/panel | 0.8kg/panel | 0.8kg/panel |
Pixel Density | 32768Pixel/m² | 16384Pixel/m² | 9216Pixel/m² |
Module Resolution | 256*32(W*H) | 128*32(W*H) | 96*24(W*H) |
Maximum Brightness | 5000(cd/m) | 5000(cd/m²) | 5000(cd/m²) |
Gray scale | 16bit | 16bit | 16bit |
Refresh rate | ≥3840(Hz) | ≥3840(Hz) | ≥3840(Hz) |
Contrast ratio | 3000:1 | 3000:1 | 3000:1 |
Scanning method | Static | Static | Static |
Color temperature | 3600-13000K | 3600-13000K | 3600-13000K |
Viewing angle | H160°/V160° | H160°/V160° | H160°/V160° |
Screen size | 1000*250*3mm(W*H*D) | 1000*250*3mm(W*H*D) | 1000*250*3mm(W*H*D) |
Module Size | 1000*250mm(W*H) | 1000*250mm(W*H) | 1000*250mm(W*H) |
Operation temperature | -20/45° | -20/45° | -20/45° |
Average Power | 180W/m² | 180W/m² | 180W/m² |
Maximum power consumption | 450W/m² | 450W/m² | 450W/m² |
Power Supply Specifications | AC100-240V | AC100-240V | AC100-240V |
Protection grade | IP4X | IP4X | IP4X |
Window glass | Floor-to-ceiling windows | Automotive glass
Large Shopping Malls
Premium Showrooms
Landmark Architecture
Get Your Custom LED Display Solution with ITFLED
